FEATURES AND APPLICATION/特性和用途
►Various high power inductors are superior to be high | ►高功率,高饱和电流,适用于表面贴装。 |
►Excellent solderabillity and high heat resistance. | ►良好的可焊性 |
►Magnerically shielded construction. | ►磁屏蔽结构 |
► Power supply for VCRS; OA equipment Digital camera, | ►录像机,笔记本电脑,OA仪器,数码相机,液晶电视,小型通 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH63-2R2M | 2.2 | 100 | 0.057 | 1.94 |
MBH63-4R0M | 4.0 | 100 | 0.070 | 1.63 |
MBH63-5R5M | 5.5 | 100 | 0.085 | 1.40 |
MBH63-100M | 10 | 100 | 0.150 | 1.10 |
MBH63-120M | 12 | 100 | 0.176 | 1.00 |
MBH63-150M | 15 | 100 | 0.212 | 0.90 |
MBH63-180M | 18 | 100 | 0.270 | 0.80 |
MBH63-220M | 22 | 100 | 0.290 | 0.74 |
MBH63-270M | 27 | 100 | 0.360 | 0.66 |
MBH63-330M | 33 | 100 | 0.420 | 0.59 |
MBH63-390M | 39 | 100 | 0.510 | 0.54 |
MBH63-470M | 47 | 100 | 0.570 | 0.50 |
MBH63-560M | 56 | 100 | 0.720 | 0.46 |
MBH63-680M | 68 | 100 | 0.920 | 0.42 |
MBH63-820M | 82 | 100 | 1.010 | 0.38 |
MBH63-101M | 100 | 1 | 1.250 | 0.34 |
MBH63-121M | 120 | 1 | 1.400 | 0.31 |
MBH63-151M | 150 | 1 | 1.770 | 0.28 |
MBH63-181M | 180 | 1 | 2.040 | 0.26 |
MBH63-221M | 220 | 1 | 2.800 | 0.23 |
MBH63-271M | 270 | 1 | 3.210 | 0.22 |
MBH63-331M | 330 | 1 | 4.150 | 0.19 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH65-100M | 10 | 100 | 0.074 | 1.35 |
MBH65-120M | 12 | 100 | 0.094 | 1.22 |
MBH65-150M | 15 | 100 | 0.109 | 1.11 |
MBH65-180M | 18 | 100 | 0.143 | 1.02 |
MBH65-220M | 22 | 100 | 0.170 | 0.91 |
MBH65-270M | 27 | 100 | 0.660 | 0.82 |
MBH65-330M | 33 | 100 | 0.270 | 0.74 |
MBH65-390M | 39 | 100 | 0.300 | 0.69 |
MBH65-470M | 47 | 100 | 0.350 | 0.62 |
MBH65-560M | 56 | 100 | 0.430 | 0.58 |
MBH65-680M | 68 | 100 | 0.530 | 0.56 |
MBH65-820M | 82 | 100 | 0.580 | 0.46 |
MBH65-101M | 100 | 1 | 0.740 | 0.42 |
MBH65-121M | 120 | 1 | 0.810 | 0.38 |
MBH65-151M | 150 | 1 | 0.910 | 0.35 |
MBH65-181M | 180 | 1 | 1.140 | 0.32 |
MBH65-221M | 220 | 1 | 1.270 | 0.29 |
MBH65-271M | 270 | 1 | 1.650 | 0.26 |
MBH65-331M | 330 | 1 | 2.170 | 0.23 |
MBH65-391M | 390 | 1 | 2.470 | 0.22 |
MBH65-471M | 470 | 1 | 2.930 | 0.20 |
MBH65-561M | 560 | 1 | 3.470 | 0.18 |
MBH65-681M | 680 | 1 | 4.360 | 0.17 |
MBH65-821M | 820 | 1 | 4.770 | 0.15 |
MBH65-102M | 1000 | 1 | 6.420 | 0.14 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH73-100M | 10 | 100 | 0.081 | 2.24 |
MBH73-120M | 12 | 100 | 0.114 | 1.89 |
MBH73-150M | 15 | 100 | 0.137 | 1.75 |
MBH73-180M | 18 | 100 | 0.155 | 1.54 |
MBH73-220M | 22 | 100 | 0.190 | 1.47 |
MBH73-270M | 27 | 100 | 0.210 | 1.40 |
MBH73-330M | 33 | 100 | 0.240 | 1.23 |
MBH73-390M | 39 | 100 | 0.320 | 1.08 |
MBH73-470M | 47 | 100 | 0.400 | 1.00 |
MBH73-560M | 56 | 100 | 0.490 | 0.91 |
MBH73-680M | 68 | 100 | 0.560 | 0.84 |
MBH73-820M | 82 | 100 | 0.690 | 0.74 |
MBH73-101M | 100 | 1 | 0.790 | 0.70 |
MBH73-121M | 120 | 1 | 0.980 | 0.63 |
MBH73-151M | 150 | 1 | 1.110 | 0.58 |
MBH73-181M | 180 | 1 | 1.450 | 0.52 |
MBH73-221M | 220 | 1 | 1.820 | 0.48 |
MBH73-271M | 270 | 1 | 2.190 | 0.42 |
MBH73-331M | 330 | 1 | 2.620 | 0.39 |
MBH73-391M | 390 | 1 | 3.330 | 0.35 |
MBH73-471M | 470 | 1 | 3.860 | 0.32 |
MBH73-561M | 560 | 1 | 4.300 | 0.29 |
MBH73-681M | 680 | 1 | 5.730 | 0.19 |
MBH73-821M | 820 | 1 | 6.540 | 0.18 |
MBH73-102M | 1000 | 1 | 8.250 | 0.16 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH74-100M | 10 | 100 | 0.070 | 1.84 |
MBH74-120M | 12 | 100 | 0.078 | 1.71 |
MBH74-150M | 15 | 100 | 0.093 | 1.47 |
MBH74-180M | 18 | 100 | 0.122 | 1.31 |
MBH74-220M | 22 | 100 | 0.140 | 1.23 |
MBH74-270M | 27 | 100 | 0.183 | 1.12 |
MBH74-330M | 33 | 100 | 0.207 | 0.96 |
MBH74-390M | 39 | 100 | 0.250 | 0.91 |
MBH74-470M | 47 | 100 | 0.300 | 0.88 |
MBH74-560M | 56 | 100 | 0.360 | 0.75 |
MBH74-680M | 68 | 100 | 0.440 | 0.69 |
MBH74-820M | 82 | 100 | 0.480 | 0.61 |
MBH74-101M | 100 | 1 | 0.560 | 0.60 |
MBH74-121M | 120 | 1 | 0.700 | 0.52 |
MBH74-151M | 150 | 1 | 0.790 | 0.46 |
MBH74-181M | 180 | 1 | 0.960 | 0.42 |
MBH74-221M | 220 | 1 | 1.220 | 0.36 |
MBH74-271M | 270 | 1 | 1.510 | 0.34 |
MBH74-331M | 330 | 1 | 1.720 | 0.32 |
MBH74-391M | 390 | 1 | 2.110 | 0.29 |
MBH74-471M | 470 | 1 | 2.430 | 0.26 |
MBH74-561M | 560 | 1 | 3.160 | 0.23 |
MBH74-681M | 680 | 1 | 3.540 | 0.22 |
MBH74-821M | 820 | 1 | 4.490 | 0.20 |
MBH74-102M | 1000 | 1 | 5.800 | 0.18 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH124-3R9M | 3.9 | 100 | 0.015 | 6.50 |
MBH124-4R7M | 4.7 | 100 | 0.018 | 5.70 |
MBH124-6R8M | 6.8 | 100 | 0.023 | 4.90 |
MBH124-100M | 10 | 100 | 0.028 | 4.50 |
MBH124-150M | 15 | 100 | 0.050 | 3.20 |
MBH124-180M | 18 | 100 | 0.057 | 3.10 |
MBH124-220M | 22 | 100 | 0.066 | 2.90 |
MBH124-270M | 27 | 100 | 0.080 | 2.80 |
MBH124-330M | 33 | 100 | 0.097 | 2.70 |
MBH124-390M | 39 | 100 | 0.132 | 2.10 |
MBH124-470M | 47 | 100 | 0.160 | 1.90 |
MBH124-560M | 56 | 100 | 0.190 | 1.80 |
MBH124-680M | 68 | 100 | 0.220 | 1.50 |
MBH124-820M | 82 | 100 | 0.260 | 1.30 |
MBH124-101M | 100 | 1 | 0.308 | 1.20 |
MBH124-121M | 120 | 1 | 0.330 | 1.10 |
MBH124-151M | 150 | 1 | 0.530 | 0.95 |
MBH124-181M | 180 | 1 | 0.620 | 0.85 |
MBH124-221M | 220 | 1 | 0.700 | 0.80 |
MBH124-271M | 270 | 1 | 0.870 | 0.60 |
MBH124-331M | 330 | 1 | 0.900 | 0.50 |
MBH124-471M | 470 | 1 | 1.350 | 0.20 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH125-1R3M | 1.3 | 100 | 0.008 | 8.00 |
MBH125-2R2M | 2.2 | 100 | 0.009 | 7.00 |
MBH125-3R3M | 3.3 | 100 | 0.010 | 6.00 |
MBH125-3R9M | 3.9 | 100 | 0.012 | 5.50 |
MBH125-4R7M | 4.7 | 100 | 0.014 | 5.00 |
MBH125-5R8M | 5.8 | 100 | 0.018 | 4.40 |
MBH125-6R1M | 6.1 | 100 | 0.020 | 4.40 |
MBH125-7R5M | 7.5 | 100 | 0.024 | 4.20 |
MBH125-100M | 10 | 100 | 0.022 | 4.00 |
MBH125-150M | 15 | 100 | 0.320 | 3.30 |
MBH125-180M | 18 | 100 | 0.045 | 3.00 |
MBH125-220M | 22 | 100 | 0.520 | 2.80 |
MBH125-270M | 27 | 100 | 0.059 | 2.30 |
MBH125-330M | 33 | 100 | 0.067 | 2.10 |
MBH125-390M | 39 | 100 | 0.090 | 2.00 |
MBH125-470M | 47 | 100 | 0.098 | 1.80 |
MBH125-560M | 56 | 100 | 0.110 | 1.70 |
MBH125-680M | 68 | 100 | 0.126 | 1.50 |
MBH125-820M | 82 | 100 | 0.160 | 1.40 |
MBH125-101M | 100 | 1 | 0.183 | 1.30 |
MBH125-121M | 120 | 1 | 0.200 | 1.10 |
MBH125-151M | 150 | 1 | 0.240 | 1.00 |
MBH125-181M | 180 | 1 | 0.300 | 0.90 |
MBH125-221M | 220 | 1 | 0.350 | 0.80 |
MBH125-271M | 270 | 1 | 0.430 | 0.75 |
MBH125-331M | 330 | 1 | 0.490 | 0.68 |
MBH125-391M | 390 | 1 | 0.580 | 0.65 |
MBH125-471M | 470 | 1 | 0.770 | 0.58 |
MBH125-561M | 560 | 1 | 1.010 | 0.54 |
MBH125-681M | 680 | 1 | 1.200 | 0.48 |
MBH125-821M | 820 | 1 | 1.340 | 0.43 |
MBH125-102M | 1000 | 1 | 1.530 | 0.40 |
COILMX | L(uH) | Test Freq (KHZ) | DCR(Ω) Max | IDC (A) |
MBH127-1R2M | 1.2 | 100 | 0.007 | 9.80 |
MBH127-3R5M | 3.5 | 100 | 0.014 | 7.50 |
MBH127-4R7M | 4.7 | 100 | 0.016 | 6.80 |
MBH127-6R1M | 6.1 | 100 | 0.018 | 6.60 |
MBH127-7R6M | 7.6 | 100 | 0.020 | 5.90 |
MBH127-100M | 10 | 100 | 0.022 | 4.90 |
MBH127-150M | 15 | 100 | 0.026 | 4.50 |
MBH127-180M | 18 | 100 | 0.039 | 3.90 |
MBH127-220M | 22 | 100 | 0.043 | 3.60 |
MBH127-270M | 27 | 100 | 0.046 | 3.40 |
MBH127-330M | 33 | 100 | 0.065 | 3.00 |
MBH127-390M | 39 | 100 | 0.073 | 2.75 |
MBH127-470M | 47 | 100 | 0.100 | 2.50 |
MBH127-560M | 56 | 100 | 0.110 | 2.35 |
MBH127-680M | 68 | 100 | 0.140 | 2.10 |
MBH127-820M | 82 | 100 | 0.160 | 1.95 |
MBH127-101M | 100 | 1 | 0.220 | 1.70 |
MBH127-121M | 120 | 1 | 0.250 | 1.60 |
MBH127-151M | 150 | 1 | 0.280 | 1.42 |
MBH127-181M | 180 | 1 | 0.350 | 1.30 |
MBH127-221M | 220 | 1 | 0.390 | 1.16 |
MBH127-271M | 270 | 1 | 0.560 | 1.06 |
MBH127-331M | 330 | 1 | 0.640 | 0.95 |
MBH127-391M | 390 | 1 | 0.700 | 0.88 |
MBH127-471M | 470 | 1 | 0.980 | 0.79 |
MBH127-561M | 560 | 1 | 1.070 | 0.73 |
MBH127-681M | 680 | 1 | 1.460 | 0.67 |
MBH127-821M | 820 | 1 | 1.640 | 0.60 |
MBH127-102M | 1000 | 1 | 1.820 | 0.55 |
